for aquariums up to 1.500 liter

hard facts  Bubble King^® DeLuxe 200 internal:
adjustable brushless DC Red Dragon^® 3  Mini Speedy skimmer pump 50 Watt 1.500 l/h
motor speed adjustable: 300-3000 1/min
Base plate: Ø 25 cm / height ~ 59 cm

Technical data Bubble King^® DeLuxe 200 internal:

Water level: ~ 180 mm up to ~ 270 mm
Weight skimmer: 12 kg inclusiv pump
Dimension skimmer: 235 mm wide / 410 mm length / ~ 585 mm height

  Data_sheet.pdf    Spare_parts_and_accessories.pdf

  Operating_and_maintenance_manual.pdf

Red Dragon^® 3 Mini Speedy pump 50 Watt / 1500 l/h

Technical data  Red Dragon^® 3 Mini Speedy pump 50 Watt / 1500 l/h air intake:
max. 50 Watt/h, adjustable 15-50 Watt
speed adjustable Brushless DC pump
Intake side: Nozzle with ozone & air plug
Pressure side: reducing ring Ø 32/25 mm
Delivery rate: from 150 to max. 1500 l/h air-intake // from 300 to max. 3000 l/h water-intake
Operating voltage: 230 Volt 50 Hz  (also in 110V/60Hz available)
Protection class pump: IP 68  control unit: IP 66
Weight pump: 3,5 kg
Height of intake side: center 60 mm
Dimension pump: 100 mm wide / 210 mm length / ~ 140 mm height
Dimension control unit: 120 mm wide / 160 mm length / ~ 65 mm height

  Data_sheet_and_spare_parts.pdf     Operating_and_maintenance_manual.pdf

• Saltwater resistant M6 grade 2 titanium screws
• Saltwater resistant parabolic rubber feet for acoustic decoupling
• Extreme low noise brushless DC skimmer-pump with grouted power electronics
• High efficient technology "Made in Germany"
• compact dimensions
• High performance ceramics bearings and hollow shaft for bypass purging in the rotor housing
• Only saltwater resistant pump with titanium rotor, titanium stator and shrivelled bearings
• Easy usage and maintenance. Low risk of calcification due to polished titanium parts and compulsory purgeing
• Heavy and massive craftsmanship against vibrations and oscillation
• CE conformity, developed and built according to VDE guidelines
